Weekly Arduino Online Proctored Webinar

$199.99

Category:

Description


Weekly (Wednesday-Thursday) First Cohort 25-27 March



This online webinar is designed to give EOD Techs the minimum knowledge required to implement Arduino in their training scenarios. Students will load source code and configure hardware to produce EOD training devices that meet or exceed current industry offerings. This Course is restricted to Active EOD and PSBT at this time. All materials for this course must be purchased on Amazon and are not provided by Improvised Electronics. Affiliate links are provided below for your convenience. The Alarm Board from the EOD Maker Box 5.0 may also be used.



  • Arduino Starter Kit
  • Solder Shield (Optional)
  • If you need tools you can get them here: EOD Tools and Kit


Day 1: Programming Concepts and Arduino Applied to IEDs- 90 Minutes


Lecture: This lecture is focused on dividing and classifying the Arduino Boards and the initial setup of the Arduino IDE and libraries.



Lab:

  • Install Arduino IDE and libraries.
  • Load Example Code



45 Minute Break


Lecture Digital Ports and Conditional Statements  90 Minutes


Lab:

  • Build Arduino Auto-Detect NO/NC IED with Auto Reset
  • Breadboard Hardware and Test



Day 2: Using the Analog Port for IED and Wire Attack Training 90 Minutes



Lecture: Voltage dividers and the analog Port 90 Minutes



Lab:

  • Build Arduino Light Meter IED (from source code).


45 Minute Break



Lecture: Arduino Applied to Basic Alarm Theory 90 Minutes


Lab:

  • Build Arduino Alarm Wire Attack Trainer IED (from source code).
